Perbesar Gambar| Fungsi : Alat ukur Gas Emisi cerobong asap (O2, CO, NO, NO2 dan SO2). |
| Spesifikasi Alat : | ||
| ▪ Parameteres | Range | Accuracy |
| 1. O2 (Oxygen) | : 0 .0-21.0 Vol % | ±0.3 Vol % |
| 2. CO (Carbon monoxide) | : 0 - 100.000 ppm | ±100 Vol ppm |
| 3. NO (Nitric oxide) | : 0 -3.000 ppm | ±5 Vol ppm |
| 4. NO2 (Nitric dioxide) | : 0 - 1.000 ppm | ±5 Vol ppm |
| 5. SO2 (Sulfur dioxide) | : 0 - 5.000 ppm | ±10 Vol ppm |
| ▪ Diffrential Pressure | : 0 to ±110 hPa | 0.3 Pa |
| ▪ Flue Gas Temperature | : -20 to 800 °C 0 to 133 °C ; ±2°C | |
| ▪ Combustion Air Temperature | : -20 to 100 °C ±1°C |
| ▪ Power Supply | : Lithium, rechargeable battery |
| 3,7V 5800 mAh, charger via USB | |
| ▪ Dimension / Weight | : 220x160x55mm without probe / 1250g |
| ▪ Length of cable hose | : 3000 mm |
| ▪ Data memory | : 1000 record |
| : Data transfer via USB, Bluetooth of Infrared | |
| ▪ Display | : Large, Color touchsreen, Display up to 14 measurement |
| and calculation values | |
| ▪ Approvals | : DIN EN 50379 Part 2 |
| ▪ Complete Unit |
| - Main unit and probe 295mm, 1,5m hose |
| - Thermal Printer and Printer paper |
| - Cable hose 3,0 mtr |
| - Gas Probe 1000mm with sinter filter |
| - Ambient temperature probe (plug) |
| - USB Charger with micro-USB Cable |
| - 25 wadding filter |
| - Manual books, certificate of calibration |
| - Carrying case |
