AQMesh|AIR QUALITY MONITORING SYSTEM AQMGP11-02 Produk ALAT MONITORING LINGKUNGAN PERDAGANGAN

AQMesh|AIR QUALITY MONITORING SYSTEM AQMGP11-02

Dapatkan Spesifikasi Harga AQMesh|AIR QUALITY MONITORING SYSTEM AQMGP11-02 Produk Terbaik dari ALAT MONITORING LINGKUNGAN PERDAGANGAN

AQMesh|AIR QUALITY MonITORING SYSTEM AQMGP11-02

Fungsi : Alat ukur kualitas udara ambient secara otomatis .

ISPU (Indeks Standar Pencemaran Udara)

Specification :
▪ Sensor life	: Up to 2 years
▪ Power Options	: Primary lithium metal batteries #3. Up to years operation
	(depending on measurement strategi) Main power option,
	External 12 DC power option, Rechargeable NiMH Battery and
	Charger option
▪ Communication	: Raw data sent to remote server via wireless
	Communications-Data access contract may be required
▪ Physical	: Enclosure Polyurethane moulded or ABS, Protection IP65
	Approx size L170xW220xH250mm (not inc antennaa 180mm)
	Weight <2kg
▪ Mounting	: Various mounting accessories available
▪ Meas. period	: Variable, from 1 minute to 1 hours
▪ Server software	: Web browser based, processing of row data to give indicate
	concentration, database storage on secure server, data
	acces-tables, graph, data downloadd, multii-user access,
	pasword controlled

Parameter yang diukur :
▪ Dust PM10	: 0 - 1,000 µg/m3
▪ NO2	: 0 - 4.000 ppb
▪ CO	: 0 - 6000 ppm
▪ SO2	: 0 - 10,000 ppm
▪ Ozone (O3)	: 0 - 1,800 ppb
▪ Temperature	: -20 to + 100°C
▪ Relative Humidity	: 0 - 100% RH

Complete Unit :

▪ Solar Panel Assembly, Including Bracket and Control

▪ Initial 2 years Contract for access to Uk Manufacture Data

▪ Included Dispaly Monitoring ± 100 x 60 cm
