| Spesifikasi Alat : |
|
|
| a. Spesifikasi Digital Photometer (Alat analisa kualitas air) : |
| ▪ |
Negara Asal |
: |
Germany |
| ▪ |
Batas ukur |
: |
380nm - 780nm |
| ▪ |
Koneksi jaringan |
: |
Bluetooth module |
| |
|
|
Dapat di applikasikan ke Handphone android |
| ▪ |
Kalibrasi |
: |
Kalibrasi otomatis |
| ▪ |
Layar |
: |
Graphical LCD |
| ▪ |
Memory |
: |
100 data penyimpanan |
| ▪ |
Bahasa |
: |
German, English, Spanish, French |
| ▪ |
Jam/Tanggal |
: |
Dapat di setting oleh pengguna |
| ▪ |
Auto-off |
: |
Default 10 minutes |
| ▪ |
Sumber tenaga |
: |
(4) AAA 1,5V batteries or 240 VAC 50/60Hz |
| ▪ |
Tombol |
: |
5 tombol pengoperasian alat |
| ▪ |
Ukuran/Berat |
: |
175mm x 88m x 59mm / 160g |
| |
|
|
|
| b. Parameter Kimia Air (Photometer Primelab 1.0) : |
| |
Parameter / Reagent |
|
Test-Range |
| |
Alkalinity / Tablet |
: |
0-500 mg/l (50 test) |
| |
Ammonia / Tablet |
: |
1-50 mg/l (50 test) |
| |
Aluminium / Tablet |
: |
0-0.3 mg/l (50 test) |
| |
Besi / Liquid |
: |
0-30 mg/l (50 test) |
| |
Chloride / Tablet |
: |
0.5-25 mg/l (50 test) |
| |
Chlorine / Tablet |
: |
0.00-8.00 mg/l (50 test) |
| |
Fluorida / Liquid |
: |
0 - 2 mg/l (50 test) |
| |
Kesadahan / Tablet |
: |
20 - 500 mg/l (50 test) |
| |
Mangan / Tablet |
: |
0.2 - 5 mg/l (50 test) |
| |
Nitrat / Pwd, Liquid |
: |
0.0 - 11 mg/l (50 test) |
| |
Nitrit / Tablet |
: |
0 - 0.5 mg/l (50 test) |
| |
Ozone / Tablet |
: |
0 - 5.4 mg/l (50 test) |
| |
Phosphate / Tablet |
: |
0 - 80 mg/l (50 test) |
| |
Potassium / Tablet |
: |
0.7 - 12 mg/l (50 test) |
| |
Sulphate / Tablet |
: |
5 - 100 mg/l (50 test) |
| |
Tembaga / Tablet |
: |
0 - 5 mg/l (50 test) |
| |
Turbidity |
: |
0 - 1000 NTU ( Tanpa reagent) |
| |
|
|
|
| c. Fisik Air : |
|
|
| Multiparameter Tester pH, Conductivity, TDS, Salinity & Temperature |
| ▪ |
Batas ukur pH |
: |
-2.00 - 16.00 pH |
| ▪ |
Batas ukur Suhu |
: |
0 - 110 °C |
| ▪ |
Batas ukur Conductivity |
: |
0.0 - 199.9μS |
| ▪ |
Batas ukur TDS |
: |
0.0 - 131.9 ppm |
| ▪ |
Batas ukur Salinity |
: |
0.0 - 99.9 ppm |
| ▪ |
Akurasi |
: |
±2% FS |
| ▪ |
Resolusi |
: |
0.1/1μS/0.01/0.1 mS |
| |
|
: |
0.1/1ppm/0.01/0.1ppt |
| ▪ |
Kompensasi |
: |
ATC: 0~50 °C |
| ▪ |
Power |
: |
DC 1.5V(UM4, AAA) baterai x 4 pcs |
| ▪ |
Dimensi |
: |
42 x 33 x 183 mm |
| ▪ |
Berat |
: |
150 gram (termasuk batera) |
| |
|
|
|
| d. Parameter Uji Makanan : |
|
|
| ▪ |
Boraks |
: |
0-50-100-150-200-5000-10.000 mg/l (50 test) |
| ▪ |
Formalin |
: |
0-200 mg/l (100 test) |
| ▪ |
Rhodamin B |
: |
0-2-10-20-30-40 mg/l (50 test) |
| ▪ |
Methyl Yellow |
: |
0-5-10-15-20-30-40-50 mg/l (50 test) |
| ▪ |
Uji Ayam Bangkai |
: |
Qualitative +/- (150 test) |
| ▪ |
Food Temp Meter |
: |
-40 to 250 °C (1 unit) |
| |
|
|
|
| e. Parameter Lingkungan Udara : |
|
|
| ▪ |
Temperatur ruang |
: |
-10 ~ 60℃ |
| ▪ |
Kelembaban |
: |
20% ~ 80%RH |
| ▪ |
Pencahayaan |
: |
0 ~ 50.000 LUX |
| ▪ |
Aliran Udara |
: |
0.4 ~ 20 m/s |
| |
|
: |
1,3 ~ 65,7 ft/s |
| |
|
: |
0.8 ~ 38.9 knots |
| ▪ |
Kebisingan Suara |
: |
30 ~ 130 dB (A) |
| |
|
: |
35 ~ 130 dB (C) |
| ▪ |
Deteksi 5 Gas Secara bersamaan (1 unit) |
| |
CH4 (Methane) |
: |
0-100 ppm |
| |
O2 (Oxygen) |
: |
0-25% Vol |
| |
CO (Carbon Monoxide)) |
: |
0-999 ppm |
| |
H2S (Hydrogen Sulfide) |
: |
0-100 ppm |
| |
SO2 (Sulfur Dioxide) |
: |
0-20 ppm |
| ▪ |
Uji Debu PM10 & PM2,5 |
: |
0 ~ 2000 µg/m3 |
| ▪ |
Uji Radiasi (β, ϒ, x-ray ) |
: |
0,05 to 999 µSv/h |
| |
|
|
|
