| Aplikasi : |
|
|
| - Rumah sakit/Klinik |
|
|
| - Laboratorium |
|
|
| - Hotel |
|
|
| - Pergudangan |
|
|
| - Perkantoran |
|
|
| - Ruang tunggu |
|
|
| |
|
|
|
| Spesifikasi : |
|
|
| 1. Parameter yang diukur : |
|
|
| ▪ |
Partikel Debu |
: |
PM 0,3um, |
| |
|
: |
PM 0,5µm, |
| |
|
: |
PM 1.0µm, |
| |
|
: |
PM 2.5µm, |
| |
|
: |
PM 10µm |
| ▪ |
Kebisingan |
: |
30~130 dB |
| ▪ |
Intensitas Cahaya |
: |
0-200.000 lux |
| ▪ |
Kecepatan Udara |
: |
0,4~30 m/s |
| ▪ |
Temperature |
: |
-20 ~ 60 °C |
| ▪ |
Kelembaban |
: |
0,1 ~ 99,9 RH |
| ▪ |
CO (Carbon Monoxide) |
: |
0 ~ 5,000 ppm |
| ▪ |
CO2 (Carbon Dioxide) |
: |
0 ~ 1,000 ppm |
| ▪ |
NO ( Nitric Oxide) |
: |
0 ~ 100 ppm |
| ▪ |
NO2 (Nitrogen Dioxide) |
: |
0 ~ 100 ppm |
| ▪ |
SO2 (Sulphur Dioxide) |
: |
0 ~ 50 ppm |
| ▪ |
HCHO (Formaldehyde) |
: |
0.00-5 ppm (0 - 5,23 mg/m3) |
| ▪ |
Radiasi |
: |
0,05~999 μSV/h |
| ▪ |
Uji Bakteri di Udara |
: |
30-120 Lpm |
| ▪ |
Uji Kadar Bau |
: |
0~999 µg/m3 (Level Bau) |
| |
|
|
|
| 2. Spesifikasi Alat : |
|
|
| A. Partikel Debu |
|
|
| ▪ |
Flow rate |
: |
2.83 l/min |
| ▪ |
Probe |
: |
Isokinetic probe |
| ▪ |
Tampilan |
: |
Max, min, rata-rata, Hold, Alarm, |
| |
|
|
Bahasa dan Suhu |
| ▪ |
Memory |
: |
5000 data |
| ▪ |
Dokumen |
: |
Sertifikat Calibrasi dari pabrik |
| |
|
|
|
| B. Kebisingan |
|
|
| ▪ |
Akurasi |
: |
Class 2 (DIN EN 61672) |
| ▪ |
Resolusi |
: |
0,1 dB |
| ▪ |
Frequency |
: |
31,5 Hz - 8 kHz |
| ▪ |
Dinamic range |
: |
50 dB |
| |
|
|
|
| C. Intensitas Cahaya |
|
|
| ▪ |
Akurasi |
: |
±2% untuk pembacaan ±1 dig |
| ▪ |
Respon Waktu |
: |
0.3 detik |
| ▪ |
Sensor |
: |
Silicon photo cel |
| ▪ |
Battre |
: |
1pcs 006P 9V Battery. |
| |
|
|
|
| D. Kecepatan udara |
|
|
| ▪ |
Air Volume |
: |
0-9999m3/min (CMM) |
| ▪ |
Satuan Ukur |
: |
°C/°F, m/s, ft/min, m3/min, km/h, |
| |
|
|
mph, knots, cms, cfm, min, max, |
| |
|
|
hold display |
| ▪ |
PC link |
: |
Yes |
| ▪ |
Ketahanan battre |
: |
100 jam |
| |
|
|
|
| E. Air Quality Monitor |
|
|
| ▪ |
CO2 Akurasi |
: |
±30 ppm, ±5% (0-5000ppm) |
| ▪ |
CO Akurasi |
: |
±10ppm (dibawah 100ppm), |
| |
|
: |
±10% pembacaan 101-500ppm |
| |
|
: |
±20% pembacaan diatas 501ppm |
| ▪ |
Suhu range / Akurasi |
: |
-20~60 °C / ±0,6°C |
| ▪ |
R/H range / Akurasi |
: |
0.1%~99,9%RH / ±3% RH |
| |
|
|
|
| F. Alat Uji Gas |
|
|
| ▪ |
Resolution |
: |
NO: 0.1ppm |
| |
|
: |
NO2: 0.02ppm / 0.1ppm |
| |
|
: |
SO2: 0.1ppm |
| ▪ |
Alarm |
: |
Audible--buzzer with ≥75dB audible |
| ▪ |
Display |
: |
LCD |
| ▪ |
Battre |
: |
PL123450, 3.7V/1500mA |
| |
|
|
|
| G. Uji Formalin di Udara |
|
|
| ▪ |
Satuan parameter ukur |
: |
ppm, mg/m3 |
| ▪ |
Resolution |
: |
0.01 ppm |
| ▪ |
Memory |
: |
32.000 point |
| ▪ |
Kabel koneksi |
: |
USB Cable |
| |
|
|
|
| H. Radiasi |
|
|
| ▪ |
Alarm |
: |
0,05 - 1,2 µSv/h |
| ▪ |
Parameter yang diukur |
: |
Beta, Gamma dan X-radiation |
| ▪ |
Kabel Koneksi |
: |
USB cable |
| |
|
|
|
| I. Kadar Bakteri Diudara |
|
|
| ▪ |
Daya Hisap |
: |
30 - 120LPM (dapat disesuaikan) |
| ▪ |
Standard piringan |
: |
90mm x 15mm |
| ▪ |
Layar Monitor |
: |
Layar LCD menampilkan kuantitas |
| |
|
|
sampling, waktu sampling dan |
| |
|
|
parameter lainnya |
| ▪ |
Penyimpanan data |
: |
Hingga 256 sampel, waktu sampel, |
| |
|
|
volume sampling |
| ▪ |
Tempat sampel |
: |
memiliki banyak lubang kecil untuk |
| |
|
|
mengurangi partikel superposisi dan |
| |
|
|
dan mengurangi kesalahan |
| |
|
|
menghitung |
| ▪ |
Kecepatan udara |
: |
0,4 m/s pada lubang sampling |
| ▪ |
Ketahanan battre |
: |
6-8 jam sesuai kekuatan daya hisap |
| ▪ |
Recharger battre |
: |
DC6V |
| |
|
|
|
| J. Uji Kadar Bau |
|
|
| ▪ |
Object Gas |
: |
Hydrogen Sulfide, Methyl Mercaptane |
| |
|
|
Ammonia |
| ▪ |
Penyimpanan data |
: |
Sampai 32,732 data |
| ▪ |
Metode pengukuran |
: |
2 sensor gas semikonduktor |
| ▪ |
Koneksi ke komputer |
: |
USB cable |
| |
|
|
|
| 3. Perlengkapan Alat |
|
|
| a. Portable Mini Incubator |
|
|
| ▪ |
Power - Adaptor |
: |
100-240v AC @320 mA |
| ▪ |
Power - Incubator |
: |
12 Volts DC @ 1 Amps |
| ▪ |
Temperature Control |
: |
MX Darlington switched solid state |
| ▪ |
Temperature |
: |
+ 5 to 45 ºC +/- 0.5 ºC |
| ▪ |
Kapasitas |
: |
±5.2 Liters |
| ▪ |
Dapat menampung |
: |
30 pcs piringan diameter 95ml |
| ▪ |
Berat inkubator |
: |
± 2.1 Kg (dengan adaptor) |
| ▪ |
Charge |
: |
Dapat di charge pada Mobil |
| |
|
|
dilengkapi kabel pemantik |
| |
|
|
|
| b. Petri Dish |
: |
100 pcs, dia 90mm |
| |
|
|
|
| c. colony Counter |
|
|
| ▪ |
Pembacaan |
: |
Digital |
| ▪ |
Layar monitor |
: |
LCD |
| ▪ |
Tenaga |
: |
16 W |
| ▪ |
Voltase |
: |
220V, 50Hz |
| ▪ |
Ukuran cawan petri |
: |
Φ 90mm, Φ50.count |
| ▪ |
Jumlah pencatatan |
: |
0-999 |
| ▪ |
Optic magnified |
: |
5X, 10X |
| ▪ |
Ukuran/berat |
: |
310x210x80 mm / 2,5 kg |
| ▪ |
Pensil Penghitung |
|
4 Digit LCD Display |
| |
|
: |
(pen Count colonies) |
| |
|
|
|
| d. Uji bau |
: |
USB Cable |
| |
|
: |
AC adapter |
| |
|
: |
Air Purifying unit |
| |
|
: |
Activated Carbon |
| |
|
|
|
