| Spesifikasi : |
|
|
| 1. Parameter Kualitas udara Faktor Fisik |
|
|
| ▪ |
Temperatur ruang |
: |
-10 ~ 60℃ |
| ▪ |
Kelembaban |
: |
20% ~ 80%RH |
| ▪ |
Pencahayaan |
: |
0 ~ 50.000 LUX |
| ▪ |
Aliran Udara |
: |
0.4 ~ 20 m/s |
| |
|
: |
1,4 ~ 72 km/h |
| |
|
: |
1,3 ~ 65,7 ft/s |
| |
|
: |
0.8 ~ 38.9 knots |
| ▪ |
Kebisingan Suara |
: |
30 ~ 130 dB (A) |
| |
|
: |
35 ~ 130 dB (C) |
| 2. Uji Kualitas Air |
|
|
| a. Photometer |
|
|
| ▪ |
Unit range |
: |
380nm - 780nm |
| ▪ |
Data Transmission |
: |
Built-in Bluetooth module |
| ▪ |
Calibration |
: |
Auto Calibration |
| ▪ |
Display |
: |
Graphical LCD |
| ▪ |
Internal memory |
: |
100 data record |
| ▪ |
Languages |
: |
German, English, Spanish, French |
| ▪ |
Clock / date |
: |
RTC (real-time clock) with data function |
| ▪ |
Auto-off |
: |
Default 10 minutes |
| ▪ |
Power |
: |
(4) AAA 1,5V batteries or |
| |
|
: |
240VAC 50/60Hz |
| ▪ |
Keypad |
: |
5 button |
| ▪ |
Size / weight |
: |
175mm x 88m x 59mm / 160g |
| |
|
|
|
| b. Reagent Test |
|
|
| |
Reagent |
|
Range |
| ▪ |
Ammonia |
: |
1-50 mg/l (50 test) |
| ▪ |
Aluminium |
: |
0-0.3 mg/l (50 test) |
| ▪ |
Besi |
: |
0-10 mg/l (50 test) |
| ▪ |
Fluoride |
: |
0-2 mg/l (50 test) |
| ▪ |
Kesadahan |
: |
20-500 mg/l (50 test) |
| ▪ |
Kekeruhan |
: |
0-1000 NTU (tidak terbatas) |
| ▪ |
Chloride |
: |
0.5-25 mg/l (50 test) |
| ▪ |
Chlorine |
: |
0-8.00 mg/l (50 test) |
| ▪ |
Mangan |
: |
0.2-5 mg/l (50 test) |
| ▪ |
Ozone |
: |
0-5.4 mg/l (50 test) |
| ▪ |
Seng |
: |
0-1 mg/l (50 test) |
| ▪ |
Sianida |
: |
0.01-0.5 mg/l (50 test) |
| ▪ |
Sulfat |
: |
5-100 mg/l (50 test) |
| ▪ |
Tembaga |
: |
0-5 mg/l (50 test) |
| ▪ |
Nitrat |
: |
0-11 mg/l (50 test) |
| ▪ |
Nitrit |
: |
0-1500 mg/l (50 test) |
| ▪ |
Phosphate |
: |
0-80 mg/l (50 test) |
| |
|
|
|
| c. Faktor Fisik Air (1 unit) |
|
|
| ▪ |
pH |
: |
-2 to 16.00 pH |
| ▪ |
Conductivity |
: |
2.00 to 100 mS |
| ▪ |
TDS |
: |
0 to 1319 ppm |
| ▪ |
Salinity |
: |
0-999 ppm |
| ▪ |
Temperature |
: |
0 to 110 °C |
| |
|
|
|
| d. Faktor Biologi (E-coli dan Total Coliform) |
|
|
| ▪ |
Test Ecoli dan Total Coliform |
: |
40 test |
| ▪ |
Comparator Bacteria (1 pcs) |
: |
1 pcs |
| ▪ |
Total Coliform |
: |
Warna kuning (Positive) |
| ▪ |
E-Coli |
: |
Biru Muda (Positive) |
| ▪ |
Sample Vessel 120ml |
: |
50 pcs |
| ▪ |
Handheld UV lamp |
: |
1 pcs |
| |
|
|
|
| 3. Uji Kualitas Makanan |
|
|
| ▪ |
Formalin |
: |
0 - 200 mg/l (100 test) |
| ▪ |
Boraks |
: |
0-10.000 mg/l (50 test) |
| ▪ |
Rhodamin B |
: |
0 - 40 mg/l (50 test) |
| ▪ |
Methyl Yellow |
: |
0 - 50 mg/l (50 test) |
| ▪ |
Uji Ayam Bangkai |
: |
Qualitative (+/-) (150 test) |
| |
|
|
|
| 4. Uji Populasi Kepadatan Lalat |
|
|
| ▪ |
Mosquito Trap |
: |
Aspirator (4 buah) |
| ▪ |
Fly grill |
: |
Bahan dari Aluminium di Cat Putih |
| |
|
: |
Stopwatch (1 pcs) |
| |
|
: |
Hand Tally counter (1 pcs) |
| |
|
: |
Tas Fly Grill (1 pcs) |
| ▪ |
Sprayer Insect |
: |
Bahan Bakar, Butane |
| |
|
: |
Kapasitas Tangki 2 Ltr |
| |
|
: |
Cooling System Pendinginan dan |
| |
|
|
membersihkan saluran bahan kimia |
| |
|
|
|
| 5. Botol Sampel Air Berpemberat |
|
|
| ▪ |
Kapasitas Botol |
: |
500 ml (Duran) |
| |
|
|
Botol dapat di diseterilkan (autoclave) |
| ▪ |
Scala Botol |
: |
100-200-300-400ml |
| ▪ |
Pemberat |
: |
Terbuat dari besi Stainless Steel |
| ▪ |
Tebal Besi |
: |
3mm |
| ▪ |
Tangkai tutup botol |
: |
±18 cm (Panjang) |
| ▪ |
Tinggi keseluruhan |
: |
38 cm |
| ▪ |
Lebar |
: |
9,5 cm |
| ▪ |
Penjepit Gelas |
: |
Terdapat pada posisi leher gelas |
| |
|
|
dilengkapi U-Clamp dan baut penjepit |
| ▪ |
Panjang Tali |
: |
±20 mtr (PE 5mm warna Merah) |
| |
|
: |
±20 mtr (PE 3mm warna Putih) |
| |
|
: |
Dilengkapi dengan rantai ±75 cm |
| ▪ |
Perlengkapan |
: |
Box Alat (bahan Plastic) |
| |
|
: |
Kartu Garansi |
| |
|
: |
Buku Petunjuk Penggunaan Alat |
