| Spesifikasi: |
|
| ▪ Measuring item |
: Smoke opacity ( %, k [m-1] ) |
| |
: RPM /oil Temperature ° C |
| ▪ Principle |
: Light extinction method |
| ▪ Light source |
: Green LED(565nm) |
| ▪ Detector |
: Photo diode |
| ▪ Range |
: 0.0~100.0% (0.00~21.42m-1 ) |
| ▪ Accuracy |
: Less than 1% |
| ▪ Warm-up time |
: 3~6 minutes |
| ▪ Display time |
: 4 times /sec |
| ▪ Power |
: 220V / 110V AC 50/60Hz |
| ▪ Temperature |
: -10~40℃ |
| ▪ Dimension |
: 450(W) x 200(D) x 245(425)(H) mm |
| ▪ Weight |
: about 7kg |
| ▪ Complete unit |
: Main Unit , RPM/ Oil temp., Built-in printer |
| |
: NDF filter, Probe and Probe hose |
