Produk Detail
Portable Octane - Cetane Analyzer SX-150
| Type |
: SX-150 |
| Merk |
: Shatex |
| Fungsi |
: Alat analisa kadar Octane (pada Bensin) dan kadar Cetane (pada Solar), |
| |
Portable Octane/Cetane Analyzer dapat diterhubung ke PC (Kompoter) melalui kabel USB, |
| |
Shatox SX-150 dapat menyimpan data dan dapat ditransfer ke komputer dengan format Exel. |
| |
|
| Specification : |
|
|
| ▪ |
Measured petrols octane numbers range |
: |
40-135 ON |
| |
Acceptable limit of octane number measurement basic error, max |
: |
±0.5 ON |
| |
Limit of acceptable difference between parallel octane number measurements, max |
: |
±0.2 ON |
| |
Petrol oxidation breakdown time measurement range |
: |
50-2400 min |
| |
Acceptable basic error limit of petrol oxidation breakdown time |
: |
10 min |
| ▪ |
Cetane numbers measurement range |
: |
20-100 CN |
| |
Acceptable basic error limit of cetane numbers, max |
: |
±1.0 CN |
| |
Acceptable difference limit between cetane numbers parallel measurements, max |
: |
± 0.5 CN |
| |
Acceptable error limit when determining diesel-fuel pour point |
: |
± 5 ºC |
| ▪ |
Kerosene content determination range in diesel fuels |
: |
0-95 % |
| ▪ |
Acceptable basic error limit when determining kerosene content in diesel fuels |
: |
3% |
| ▪ |
Measurement time |
: |
1–5 sec |
| ▪ |
Insufficient power supply indication operation threshold |
: |
5.4 V |
| ▪ |
Instrument useful life |
: |
minimum 6 years |
| ▪ |
Overall dimensions of: |
|
|
| |
Electronic module |
: |
211 х 100 х 45 mm |
| |
Sensor #1 |
: |
60 х 100 mm |
| |
Instrument weight |
: |
680 g |
| ▪ |
The instrument capabilities : |
|
|
| |
Determining gasoline octane level. Complies with ASTM D 2699-86, ASTM D 2700-86 |
| |
Determining diesel fuel cetane level. Complies with ASTM D 4737-03, ASTM D 613, EN ISO 5165 |
| |
Determining solidification temperature and diesel fuel type (reference parameter). |
| |
Determining content of kerosene in diesel fuel (reference parameter). |
| |
Determining petrol breakdown time (oxidative stability). Complies with ASTM D 525 |
| ▪ |
Delivery package : |
| |
Electronic computing module |
| |
Sensor #1 |
| |
Sample imitator |
| |
Mini-USB cable |
| |
User manual |
