Home > Produk > Portable Octane - Cetane Analyzer SX-250 Portable Octane - Cetane Analyzer SX-250

Perbesar Gambar

Portable Octane - Cetane Analyzer SX-250

Produk Lain

Detail Produk

Type	: SX-250
Merk	: Shatex
Fungsi	: alat analisa kadar Octane (pada Bensin) dan kadar Cetane (pada Solar) dan dapat menentukan
	kadar air dalam solar. Portable Octane/Cetane Analyzer dapat diterhubung ke PC dengan kabel USB,

Specification :
▪	Range Petrol octane level	:	40-135 ON
	Acceptable limit of octane number measurement basic error, max	:	± 0.5 ON
	Limit of acceptable difference between parallel octane number
	measurements, max	:	± 0.2 ON
	Range of petrol oxidation breakdown time measurement	:	50-2400 min
	Acceptable basic error limit of petrol oxidation breakdown time	:	10 min
▪	Range of measured cetane level	:	20-100 CN
	Acceptable basic error limit of cetane numbers, max	:	±1.0 CN
	Acceptable difference limit between cetane numbers parallel
	measurements, max	:	± 0.5 CN
	Acceptable error limit when determining diesel-fuel pour point	:	± 5 ºC
	Kerosene content determination range in diesel fuels	:	0-95 %
	Acceptable basic error limit when determining kerosene content in diesel fuels	:	3%
▪	Range of measured purity of motor oils	:	95-100%
	Acceptable basic error limit when determining purity of motor oils	:	0.01%
▪	Range of measured dielectric permeability of oil products	:	1-5 units
	Range of measured water content in diesel	:	0-4%
	Acceptable basic error limit when determining water content in diesel	:	0.01%
	Measurement time	:	1–5 sec
	Insufficient power supply indication operation threshold	:	5.4 V
	Instrument useful life	:	minimum 6 years
▪	Overall dimensions of
	electronic module	:	211 х 100 х 45 mm
	sensor #1	:	60 х 100 mm
	Instrument weight	:	680 g

▪	Instrument capabilities
	Determining gasoline octane level. Complies with ASTM D 2699-86, ASTM D 2700-86.
	Determining diesel fuel cetane level. Complies with ASTM D 4737-03, ASTM D 613, EN ISO 5165.
	Cold filter plugging point and diesel fuel type (reference parameter).
	Determining content of kerosene in diesel fuel (reference parameter).
	Determining petrol breakdown time (oxidative stability). Complies with ASTM D 525.
	Determining purity (purification) level of motor oil
	Determining dielectric permeability of oil products (Eps)
	Determining water content in diesel (%
▪	Delivery package:
	Electronic computing module
	Sensor #1
	Sample imitator
	Mini-USB cable
	User manual
	Warranty certificate
	Quick start guide
	Tool canvas bag
