| Spesifikasi : |
|
|
| ▪ |
6 Channel |
: |
0.3 μm, 0.5 μm, 1.0 μm, 2.5 μm, 5.0 μm, 10.0 μm |
| ▪ |
Counting Mode |
: |
Concentration, Cumulative, Diffrential |
| ▪ |
Counting Eficiency |
: |
50% at 0.3 μm; 100% for particles > 0.45 μm |
| ▪ |
Flow rate |
: |
2.83 l/min (0.1 ft³/min), |
| |
|
|
controlled by internal pump |
| ▪ |
Light source |
: |
Laser class 3B, wave length 780 nm, 90 mW |
| ▪ |
Isokinetic probe |
: |
Isokinetic probe |
| ▪ |
Data storage |
: |
5,000 data records on the internal flash memory |
| ▪ |
Display |
: |
2.8 inch colour LCD display, 320 x 240 pixels |
| ▪ |
Function |
: |
Maximum, minimum and average display |
| |
|
|
measured value hold function, alarm function, |
| |
|
|
language selection, °C/°F switch. |
| ▪ |
Power Supply |
: |
Battery type: NiMH battery |
| ▪ |
Dimension |
: |
L x W x H: 57 x 75 x 240 mm / 570g |
| ▪ |
Complete Unit |
: |
Main Unit, Mini Tripod, Zero filter and connection |
| |
|
|
hose, Battery charger, USB cable and |
| |
|
|
Software, Manual books, Certificate Calibration, |
| |
|
|
Carrying case |
