Spesifikasi : |
|
|
▪ |
Range |
: |
A-weighting 30 ~ 130 dB |
|
|
: |
C-weighting 35 ~ 130 dB |
▪ |
Resolution |
: |
0.1 dB |
▪ |
Frequency |
: |
A.C. 31.5 ~ 8, 000 HZ |
▪ |
Microphone |
: |
Electret condenser microphone. |
▪ |
Attenuator |
: |
30 ~ 80 dB, 50 ~ 100 dB, 80 ~ 130 dB |
|
|
: |
50 dB on each step , with over/under range alarm. |
▪ |
Response |
: |
fast, slow, max-hold Decay0.2dB/ 2mm |
▪ |
Calibration |
: |
Internal oscillation system. |
|
|
: |
( 1 KHZ square wave generator, 94dB) |
▪ |
Display |
: |
3½ digital L.C.D. display. |
|
|
: |
Output : AC 0.5Vrms corresponding to each step, |
|
|
: |
impedance 600© : DC 0.3 ~ 1.3 VDC, 10mV/ dB |
|
|
: |
impedance 100© . |
▪ |
Power |
: |
one 006p 9V battery |
▪ |
Dimension |
: |
220L × 80W × 30D mm |
▪ |
Weight |
: |
approx. 250 grams |
