PORTABLE SOUND LEVEL METER TYPE 1 AND CALIBRATOR - 6238
- Harga：
- Nego
- Brand：
- ACO
- Pembelian Minimal：
- 1 Unit
- Pembelian Maksimal：
- 10 Unit
- Pengiriman：
- 3 sejak pembayaran
- Pembelian Maksimal：
- 10 Unit
- Diperbarui：
- 22-05-2019 11:16
- Dilihat：
- 2.510 Kali
PORTABLE SOUND LEVEL METER TYPE 1 AND CALIBRATOR - 6238
PORTABLE SOUND LEVEL METER TYPE 1 AND CALIBRATOR - 6238
| |
| Fungsi : Alat ukur kebisingan suara. |
| |
| Specification : |
|
|
| A. Sound Level Meter |
|
|
| ▪ |
Level Range |
: |
20~80dB |
| |
|
: |
20~90dB |
| |
|
: |
20~100dB |
| |
|
: |
20~110dB |
| |
|
: |
30~120dB |
| |
|
: |
40~130dB |
| |
|
: |
0~80dB |
| |
|
: |
0~dB function in ON |
| ▪ |
Frequency Range |
: |
5Hz～20kHz, 20Hz～12.5kHz (Low) |
| ▪ |
Linearity Range |
: |
100dB |
| ▪ |
Measurement |
: |
SPL, SPL-A, SPL-C, LAeq, LAe, LAmax, LAn, |
| |
|
|
Lpeak, Lcpeak, LAtm5, LAi, LAieq |
| ▪ |
Weighting Level |
: |
(A) 28~130dB (0~80dB/0-dB function in ON) |
| |
|
: |
(C) 37~130dB |
| |
|
: |
(Z) 39~130dB (Flat) |
| |
|
: |
(C) 55~135dB (Peak) |
| |
|
: |
(Z) 60~135dB (Flat) |
| ▪ |
Time Weighting |
: |
Fast, Slow, Impulse |
| ▪ |
Freq. Weighting |
: |
A、C、Z(FLAT) |
| ▪ |
Measurement Time |
: |
1s/3s/5s/10s/1min/5min/10min/15min/ |
| |
|
|
30min/1h/8h/12h/24h |
| ▪ |
Display |
: |
Liquid crystal and Backlight(128×64 points) |
| ▪ |
Date |
: |
year/month/day/hour：minute：second |
| ▪ |
Standard |
: |
JIS C1509-1:2005 Class II |
| |
|
|
IEC 61672-1:2002 Class II |
| |
|
|
|
| B. Octave Real-time Analysis |
| ▪ |
Measurement mode |
: |
Sound pressure level(Lp) |
| |
|
|
Equivalent continuous sound pressure |
| |
|
|
level(Leq), Sound exposure level(LE) |
| |
|
|
Maximum sound pressure level(Lmax) |
| ▪ |
1/1-octave filter |
: |
16Hz,31.5Hz,63Hz,125Hz,250 Hz,500Hz, |
| |
|
|
1kHZ, 2kHZ, 4kHz,8kHz,AP,OA |
| ▪ |
1/3-octave filter |
: |
12.5Hz,16Hz,20Hz,25Hz,31.5Hz,40Hz,50Hz, |
| |
|
|
63Hz, 400Hz,500Hz,630Hz,800Hz,1kHz, |
| |
|
|
1.25kHz,1.6kHz, 2kHz,2.5kHz,3.15kHz, 4kHz, |
| |
|
|
5kHz,6.3kHz,8kHz, 10kHz,12.5kHz, 16kHz, |
| |
|
|
AP,OA 80Hz, 100Hz,125Hz,160Hz,200Hz, |
| |
|
|
250Hz, 315Hz, |
| ▪ |
Step Level range |
: |
10~80dB, 20~90dB, 30~100dB, 40~110dB, |
| |
|
|
50~120dB, 60~130dB (-10~60dB, 0~70dB, |
| |
|
|
10~80dB/0-dB function in ON) |
| |
|
|
|
| C. Sound Calibrator |
|
|
| ▪ |
Range |
: |
94 dB |
| ▪ |
SPL tolerance |
: |
±0,3 dB |
| ▪ |
Nominal Frequency |
: |
1000Hz |
| ▪ |
Frequency Tolerance |
: |
±0,1% |
| ▪ |
Cover Microphone |
: |
Measurement Microphone 1-inch and 1/2-inch |
| |
|
|
(Included 1/2-inch microphone Adapter) |
| |
|
|
|
| D. Complete Unit |
: |
Mirophone / preamp |
| |
|
: |
Windscreen |
| |
|
: |
SD card |
| |
|
: |
Sound Calibrator |
| |
|
: |
Octave Real-time 1/1-1/3 |
| |
|
: |
Exlusive printer |
| |
|
: |
RS232 interface cable |
| |
|
: |
Roll Paper 10 pcs |
| |
|
: |
Screwdrive |
| |
|
: |
Software |
|
