| Spesifikasi |
|
| 1. Aplikasi dan Kekuatan Listrik |
|
| ▪ Aplikasi |
: Storage of general (non-flammable) |
| |
laboratory materials |
| ▪ Volume Penyimpanan |
: 25 liters (0.9 cu.ft.) |
| ▪ Kapasitas Muat |
: 18 standard 2" boxes |
| ▪ Suhu |
: -86°C to -20°C @ 32°C (90°F) ambient, |
| |
uniformity ± 0.75°C top to bottom, adjustable in 1°C |
| |
increments Presets for -86°C, -40°C and -20°C |
| ▪ Daya Listrik |
: 120V or 240V, AC; 60Hz or 50Hz; or |
| |
12V DC from mobile source |
| |
: 280 watts (3.6 amps @120V, 1.8 amps @240V ) |
| ▪ Otomatis Daya Listrik C |
: 88V to 264V, 50 or 60 Hz |
| ▪ Kekuatan Listrik |
: 15 amp atau greater grounded circuit |
| ▪ Sertifikasi |
: CE |
| ▪ Tingkat Kebisingan |
: Sama dengan Perlengkapan Laboratorium |
| |
|
| 2. Kontroler |
|
| ▪ Type |
: Kontrol Mikroprosesor |
| ▪ Pengamanan |
: Lockable lid |
| ▪ Alarm |
: Setpoint ± 10°C Warm and Cold |
| ▪ Sensor kontrol |
: One RTD (PT100 Class B) |
| |
|
| 3. Sistem Pendingin |
|
| ▪ Mesin Pendingin |
: Pengisian Ulang Mesin Pemutar bebas piston |
| |
Dengan Modulasi secara kontinyu |
| ▪ Tekanan Panas |
: Gravitasi mendorong Thermosiphon bekerja pada |
| |
: media pendingin dari 10 hingga 25gr |
| |
: Tergantung pada media yang digunakan |
| ▪ Pendingin |
: R-508B nonflammable CFC/HCFC-Free |
| ▪ Evaporasi |
: Cold wall (inner liner) |
| ▪ Metode Pendinginan |
: Manual |
| |
|
| 4. Tampilan Data, Kabinet Kosong |
|
| ▪ Energi Tetap |
: < 2.8 kWh/day at -80°C Setpoint |
| ▪ Disipasi Panas |
: 403 BTU/h (load to HVAC) at -80°C Setpoint |
| ▪ Tarikan |
: dari 25° C Ambient : 2,2 hours |
| ▪ Pemanasan |
: 30 minutes to -60°C |
| |
: 70 minutes to -40°C |
| |
: 130 minutes to -20°C |
| |
|
| 5. Dimensi dan Konstruksi |
|
| ▪ Interior |
: (L x W x D) 332 x 221 x 340 mm |
| ▪ Eksterior |
: (L x W x D) 692.5 x 350 x 460 mm |
| ▪ Berat Bersih |
: Empty 21 kg (46 lbs.), nominal |
| ▪ Berat Pengiriman |
: 26.3 kg (58 lbs.), nominal |
