| Spesifikasi : |
|
| ▪ Wavelength Range |
: 340 - 1000 nm |
| ▪ Wavelength Width |
: 8nm in entire region |
| ▪ Wavelength Accuracy |
: ±2nm at 365, 585 and 879nm |
| ▪ Wavelength Scale |
: 1nm scale |
| ▪ Optic Path Length |
: 10mm |
| ▪ Spectroscope |
: Diffraction grating, |
| |
number of grooves 1200 lines/nm |
| ▪ Stray Radiant Energy |
: <0.5%T typical at 400nm |
| ▪ Display |
: LCD Display |
| ▪ Photometric Range |
:- 0.200 to 3.000ABS |
| |
: 0.0 to 200%T |
| |
: 0.000 to 2000C |
| ▪ Photometric accuracy |
: ±2%T |
| ▪ Measuring Mode |
: 1. Normal Mode |
| |
: 2. Timer Mode-Measuring Interval 1-60 sec |
| |
: Time limit 5960 sec |
| ▪ Detector |
: High Sensitivity silicon photocell |
| ▪ Light Source |
: Bright intensity lamp |
| ▪ Sample Volume |
: 1.0 ml(Minimum) |
| ▪ Sample Container |
: Square cuvette 10x10x45(L) mm |
| |
: Round cuvette 10(D)x12(OD)x105(L)mm |
| ▪ Printer interface |
: Centronic (D-SUB 25pins) |
| ▪ Serial interface |
: RS-232C |
| ▪ Power Requirements |
: 100 - 240 VAC, 50/60 Hz, 15W |
| ▪ Dimensions |
: 270 (W) ×285 (D) ×155 (H) nm |
| ▪ Weight |
: Net 4.8 kg (Main body) |
| |
|
| Standard Accessories |
|
| ▪ Square cuvette 2 pcs |
|
| ▪ Round Cuvette 10 pcs |
|
| ▪ Cuvette Holder 1 pcs |
|
| ▪ Power Code 1 pcs |
|
| ▪ Vinyl Dust Cover 1 pcs |
|
| ▪ Operation Manual 1 copy |
|
