| Spesifikasi : |
|
| a. Parameter : |
|
| ▪ Nitrit |
: 0 - 1500 mg/l (50 test) |
| ▪ Nitrat |
: 0 - 11 mg/l (50 test) |
| ▪ Ammonia |
: 0 - 1 mg/l (50 test) |
| ▪ Phosphate |
: 0 - 80 mg/l (50 test) |
| ▪ COD |
: 0 - 150 mg/l (50 test) |
| ▪ COD |
: 0 - 1.500 mg/l (50 test) |
| ▪ Cyanida |
: 0.01 - 0.5 mg/l (50 test) |
| |
|
| b. Photometer : |
|
| ▪ Unit range |
: 380nm - 780nm |
| ▪ Data Transmission |
: Built-in Bluetooth module |
| ▪ Calibration |
: Auto Calibration |
| ▪ Display |
: Graphical LCD |
| ▪ Internal memory |
: 100 data record |
| ▪ Languages |
: German, English, Spanish, French |
| ▪ Clock / date |
: RTC (real-time clock) with data function |
| ▪ Auto-off |
: Default 10 minutes |
| ▪ Power |
: (4) AAA 1,5V batteries or 240VAC 50/60Hz |
| ▪ Keypad |
: 5 button |
| ▪ Size / weight |
: 175mm x 88m x 59mm / 160g |
| |
|
| c. Complete Unit : |
|
| 1. Carrying case |
|
| 2. Glass Cuvette |
: 4 x 24mm / 10ml glass cuve |
| 3. Cleaning brush |
: Stirring rod Cleaning brush |
| 4. Connetion to PC |
: Bluetooth USB dongle |
| 5. Thermoreactor : |
|
| ▪ Reactor type |
: Dry temperature control device |
| ▪ Number of vial cells |
: 16 cells shafts for reaction cell 16mm |
| ▪ Temperature setting |
: 100˚C, 120˚C, 150˚C, via fixed programs, and 50˚C |
| |
to 199˚C user setting |
| ▪ Heating rate 25˚C to |
: 100˚C approx. 5 min. : 120˚C approx. 6 min. |
| |
: 150˚C approx.9 min. : 165˚C approx.11 min. : 199˚C |
| |
approx. 15 min. |
| ▪ Pre-stored programs |
: 165˚C / 20 min. : 150˚C / 2 hour : 150˚C/ 20 min. |
|
: 120˚C / 2 hour |
| |
: 120˚C / 1 hour : 120˚C / 30 min. : 100˚C / 1 hour |
| ▪ Programmable |
: 50˚C to 199˚C (Temp range) |
| ▪ Programmable time range |
: 0-18 hours, Audio signal and heating stopped when |
| |
the time expired |
| ▪ Temperature correction |
: ±9˚C adjustment for thermoblock |
| ▪ Power supply |
: 220 VAC ±10%, 50/60 Hz |
| ▪ Power consumption |
: 250 W |
| ▪ Dimension |
: 320 x 210x 103 mm (Lx W x H) |
| ▪ Weight |
: Approx. 3kg |
