Perbesar Gambar| Fungsi : Alat inspeksi pipa, NDT, Saluran air limbah, ruang berongga, tangki dengan kamera. |
| Specification : | |
| A. Wide Range of Applications | : Waste water pipes of Ø 40 mm and larger |
| : Ventilation lines of Ø 40 mm and larger | |
| : Inspect hollow spaces; e.g. in front-wall installations | |
| : Flue gas lines up to approx. Ø 125 mm | |
| B. Monitor | |
| ▪ Dimension housing | : 176 x 114 x 32 mm |
| ▪ TFT display | : 7" / 16:9 format |
| ▪ Video out | : RCA Signal |
| ▪ Weight | : 400 g |
| ▪ Power supply | : Space for 2 rechargeable batteries |
| each 12 v or via power pack | |
| ▪ Battery operation time | : Max 2 rechargeable batteries, each 120 mins |
| C. Miniature camera head, color Φ 26 mm | |
| ▪ Type | : 1/3" Color CMOS |
| ▪ Resolution | : 420 lines |
| ▪ Pixels | : 768 x 576 (PAL), 656 x 492 (NTSC |
| ▪ Light sensitivity | : 0.5 Lux |
| ▪ Lens | : f = 2.3 mm, F = 2.5 |
| ▪ Light source | : 12 white LEDs |
| ▪ Degree of protection | : Waterproof to IP 67 |
| ▪ Dimensions / weight | : Ø 26 x 38 mm/ 240g |
| D. Distance measurement : | |
| ▪ Unit | : Electronic meter counter |
| E. Plastic case | |
| ▪ Dimensions / weight | : 51 x 43 x 17 cm / 7 kg |
| F. Memory | |
| ▪ Recording | : 4 GB SD card (5 h recording capacity) |
| ▪ Interface | : Mini USB port |
| G. Locator sender | |
| ▪ Transmitter frequency | : 8,9 kHz |
| H. Locator Receiver | |
| ▪ Display | : Graphic visualization of transmitted position |
| : Output impedance Headphones 32 Ohm | |
| ▪ Power supply | : 3.7 V Li-Ion rechargeable battery |
| ▪ Dimension / weight | : 32 x 14 x 7 cm / 605 g |
| I. Complete unit | |
| - Camera | |
| - Color camera head Φ 26mm | |
| - TFT monitor 7", 2m cable | |
| - Push rod Φ 6mm | |
| - Digital meter counter | |
| - 1 anti slide mat | |
| - 1 NiMH battery and charger | |
| - Plastic case | |
| - Photo and video record | |
| - Level indicator | |
| - Video setting | |
| - 20mm push rod | |
| - Manual books |
