Perbesar Gambar| Fungsi: alat deteksi suhu tubuh manusia pada umumnya ditempatkan di Bandara pintu masuk kedatangan |
| orang dari negara lain, untuk mendeteksi Virus SARs, Avian Flu/ Epidemic Screening/Swine Influenza A/ |
| H1N1 dan Virus Ebola. |
| Spesifikasi : | |||
| A. Thermal Camera | |||
| ▪ | Lens | : | 19mm (FOV: 24º x 18º) |
| ▪ | Focal Plane Array | : | Micro-bolometer |
| (Amorphous silicon or vanadium oxide) | |||
| ▪ | Image Frequency | : | 7.5 Hz (NTSC) or 8.3 Hz (PAL)* |
| ▪ | Spectral Range | : | 8 -- 14 μm |
| ▪ | Number of Pixels | : | 324 x 256 |
| ▪ | NETD | : | 0.05ºC @ 30ºC |
| ▪ | Video output | : | Network digital |
| B. Visual Camera | |||
| ▪ | Image Sensor | : | 1/3" 1.3 Million Pixel CMOS Sensor |
| ▪ | Video frame Output Rate | : | PAL: 25 fps (1280x960)/ NTSC:30 fps (1280x960) |
| C. Software User Interface | |||
| ▪ | Data Display | : | 640 x 480 on screen/processing |
| ▪ | Visual Alarm | : | User definable temperature scale and alarm |
| trigger point | |||
| ▪ | Alarm Function | : | Ignore Mode or Save Alarm Mode |
| Sound/Visual//network alarm | |||
| (saves images to hard drive and creates | |||
| log file for easy retrieval and review) | |||
| D. Network Function | |||
| ▪ | Supported Protocols | : | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, |
| PPPoE, SMTP, NTP, UpnP, SNMP, FTP, 802.1x, | |||
